Customize toolbar buttons

PC Customize toolbar buttons

This article was :

published

updated

You can customize the buttons on the toolbar in MetaTrader4 (MT4) / MetaTrader5 (MT5). Increase your efficiency by placing frequently used buttons on the toolbar for quick access. The toolbar settings will be saved, even after shutting down MT4/MT5.

Step 1

There are four types of toolbars on MT4: Standard, Charts, Line Studies, and Timeframes. Right-click on the toolbar you wish to customize.

Standard

Basic commands of MT4 are collected.

Charts

Commands for displaying charts are collected.

Line Studies

Line tools for chart analysis are collected.

Timeframes

Timeframes are collected.

Related article: Customize timeframe toolbar

Step 2

Right-click on the toolbar you wish to modify and select "Customize" on the context menu.

Step 3

Open the customize toolbar window. The "Available" on your left side shows buttons not displayed on the toolbar. The "Selected" on your right shows buttons that are currently being displayed on the toolbar.

To add a button to the toolbar

Select a button you wish to add to the toolbar in the "Available" field and click "Insert ->".

To remove a button from the toolbar

Select a button you wish to remove from the toolbar in the "Selected" field and click "<- Remove".

To add or remove a separating line

To add a separating line, select the line in the "Available" and click "Insert ->". To remove a line, select the line in the "Selected" and click "<- Remove".

To reset the toolbars to default settings

Click "Reset".

To rearrange the display order of the buttons

Select a button you wish to move in the "Selected" and click "Up" or "Down" to change the location.

Step 1

There are three types of toolbars on MT5: Standard, Line Studies, and Timeframes. Right-click on the toolbar you wish to customize.

Standard

Basic commands of MT5 are collected.

Line Studies

Line tools for chart analysis are collected.

Timeframes

Timeframes are collected.

Related article: Customize timeframe toolbar

Step 2

Select "Customize" on the list.

Step 3

Open the customize toolbar window. The "Available buttons" on your left side shows buttons not displayed on the toolbar. The "Selected buttons" on your right shows buttons that are currently being displayed on the toolbar.

To add a button to the toolbar

Select a button you wish to add to the toolbar in the "Available buttons" and click "Insert ->".

To remove a button from the toolbar

Select a button you wish to remove from the toolbar in the "Selected buttons" and click "<- Remove".

To add or remove a separating line

To add a separating line, select the line in the "Available buttons" and click "Insert ->". To remove a line, select the line in the "Selected buttons" and click "<- Remove;".
